| XAG P100 Pro 2023 Agricultural Drone | |||
| System | Type | Parameter | P100 Pro |
| Flight platform | Baisc Parameters | Overall dimensions | 2927 x 2868 x 323mm (Blades unfolded) 893 x 1095 x 345mm (Blades folded, Arm folded) |
| Rated load | 50kg | ||
| Motor | Maximum tension | 52kg | |
| Foldable propeller | Diameter*screw pitch | 55*15 inch | |
| RevoSpray | Smart Liquid Tank | Rated Volume | 50L (50kg) |
| High-Frequency Pulse Peristaltic Pump | Max. operating flow rate | 22.0 L/min | |
| Flow rate (single pump) | 0.5~11.0 L/min | ||
| RevoCast | Smart Granule Container | Rated Volume | 80L (50kg) |
| Screw Feeder | Maximum speed | 410 r/min | |
| Max. Discharge Rate¹³ | 150 kg/min | ||
| Centrifugal spreading disc | Spreading Width¹⁴ | 3-7 m | |
| Obstacle Sensing & Avoidance System | 4D Imaging Radar | Sensing Range | 1.5 ~ 80 m |
| Sensing Mode | Millimetre-wave imaging, MIMO | ||
| Relative Speed of Safe Obstacle Avoidance | ≤13.8 m/s | ||
| Approach path | ≈20 m | ||
| Maximum Flight Speed | ≈13.8 m/s | ||
| Maximum Discharge Rate¹³ | ≈150 kg/min | ||
| Single load of fertilizer | ≈50 kg | ||
| Flight time | ≈ 1 min 10 s | ||
| A set of batteries can be fully loaded for spray and cast operations | 7-8 Vehicles | ||
| Total operating time of a set of batteries | ≈ 15-18 min (Include filling fertilizer ) | ||
